產品詳情
TECHNICAL SPECIFICATIONS | |
Measuring Range | 0–1 ppm |
Sensitivity Range | 650 nA/ppm ± 150 nA/ppm |
Zero Current at 20℃ | <±10 nA |
Resolution at 20℃ | < 0.02 ppm |
Bias Potential | 0 mV |
Linearity | < 10% full scale |
Response Time at 20°C | |
t50 | < 60 s calculated from 2 min. exposure time at 40% r.H. |
T90 | < 120 s calculated from 2 min. exposure time at 40% r.H. |
Long Term Sensitivity Drift | < 5% per 6 months |
Operation Conditions | |
Temperature Range | -20°C to +40°C |
Humidity Range | 15–90% r.H., non–condensing |
Effect of Humidity | no effect |
Sensor Life Expectancy | > 12 months |
Warranty | 7 months |
